Description
90-MIBDK0-G0EAY00Z - Asus SABERTOOTH X58 Socket LGA1366 Intel X58 + ICH10R Chipset ATX System Board Motherboard Supports Core i7 Extreme Edition/ Core i7 Series DDR3 6x DIMM
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
ATX
CPU Socket Type
LGA 1366
Supported CPU(s)
Intel Core i7 Processor, Intel Core i7 Processor Extreme Edition
Chipset
Intel X58 Express
South Bridge Chipset
Intel ICH10R
Number of Memory Slot(s)
6
Number of Memory Channel(s)
3
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-12800 (DDR3-1600), PC3-14900 (DDR3-1866), PC3-8500 (DDR3-1066)
Maximum Installed Memory
24 GB
Expansion Slots
PCI-E 2.0 x16, PCI-E x1, PCI-E x16
Expansion Slots Details
2 x PCIe 2.0 x16 (dual x16), 1 x PCIe x16 (x4 mode), 2 x PCIe x1, 1 x PCI
Storage Controller Details
Intel ICH10R controller, 6 x SATA 3Gb/s port(s), black, Support Raid 0, 1, 5, 10, Marvell PCIe 9128 controller : *1, 2 x SATA 6Gb/s port(s), gray, JMicron JMB362 controller, 1 x Power eSATA 3Gb/s port(s), green, 1 x eSATA 3Gb/s port(s), red
Network
Gigabit Ethernet
Connectors/Ports
8-pin 12V Power Connector, Audio-In, Audio-Out, Chassis Fan Connector, CPU Fan Connector, PS/2 Keyboard, PS/2 Mouse, RJ-45, USB 2.0
Connectors/Ports Details
Back I/O Ports, 1 x PS/2 keyboard/mouse combo port(s), 1 x eSATA 3Gb/s, 1 x Power eSATA 3Gb/s, 1 x IEEE 1394a, 1 x LAN (RJ45) port(s), 6 x USB 2.0, 1 x Optical S/PDIF out, 6 x Audio jack(s), , Internal I/O Ports, 3 x USB 2.0 connector(s) support(s) a
Warranty Information
8
