Description
90-MIBDV0-G0EAY0DZ - Asus P8P67-M Socket LGA1155 Intel P67 Chipset Micro-ATX System Board Motherboard Supports Core i7 / i5 / i3 Series DDR3 4x DIMM
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
Micro ATX
CPU Socket Type
LGA 1155
Supported CPU(s)
Intel Core i3 Processor, Intel Core i5 Processor, Intel Core i7 Processor
Supported CPU Technologies
Intel Turbo Boost Technology
Chipset
Intel P67 Express
Number of Memory Slot(s)
4
Number of Memory Channel(s)
2
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-12800 (DDR3-1600), PC3-14900 (DDR3-1866), PC3-8500 (DDR3-1066)
Maximum Installed Memory
32 GB
Expansion Slots
PCI-E 2.0 x1, PCI-E 2.0 x16
Expansion Slots Details
1 x PCIe 2.0 x16 (blue), 1 x PCIe 2.0 x16 (x4 mode, black), 1 x PCIe 2.0 x1, 1 x PCIe x1
Storage Controller
SATA 3.0 Gbps, SATA 6.0 Gbps
Storage Controller Details
Intel® P67(B3) chipset, 4 x SATA 3Gb/s port(s), blue, 2 x SATA 6Gb/s port(s), white, Support Raid 0, 1, 5, 10, JMicron® JMB361 controller, 1 x UltraDMA 133/100/66 for up to 2 PATA devices , navy blue, 1 x eSATA 3Gb/s port(s), red
Audio Controller
Realtek ALC887-VD2
Network
Gigabit Ethernet
Connectors/Ports
Chassis Fan Connector, CPU Fan Connector, PS/2 Keyboard, PS/2 Mouse, RJ-45, TPM Header, USB 2.0, USB 3.1
Connectors/Ports Details
Back I/O Ports, 1 x PS/2 keyboard (purple), 1 x PS/2 mouse (green), 1 x eSATA 3Gb/s, 1 x IEEE 1394a, 1 x LAN (RJ45) port(s), 2 x USB 3.1 Gen 1, 6 x USB 2.0, 1 x Optical S/PDIF out, 6 x Audio jack(s), , Internal I/O Ports, 3 x USB 2.0 connector(s) sup
