Description
90-MSVCW0-G0EAY00Z - Asus P7F7-E WS Supercomputer Socket LGA1156 Intel 3450 + Nvidia NF200 Chipset ATX System Board Motherboard Supports Core i7 / Core i5 / Pentium Series DDR3 6x DIMM
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
ATX
CPU Socket Type
LGA 1156
Supported CPU(s)
Intel Core i3 Processor, Intel Core i5 Processor, Intel Core i7 Processor
Chipset
Intel 3450
Number of Memory Slot(s)
6
Number of Memory Channel(s)
2
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-16000 (DDR3-2000), PC3-6400 (DDR3-800), PC3-8500 (DDR3-1066)
Maximum Installed Memory
16 GB
Expansion Slots
PCI-E 2.0 x16
Expansion Slots Details
4 x PCIe 2.0 x16 (dual x16 or quad x8), 3 x PCIe x1
Storage Controller
SATA 6.0 Gbps
Audio Controller
VIA VT2020
Network
Gigabit Ethernet
Connectors/Ports
Audio-In, Audio-Out, DVI, PS/2 Keyboard, USB 2.0, USB 3.1
Connectors/Ports Details
Back I/O Ports, 1 x PS/2 keyboard/mouse combo port(s), 1 x DVI, 1 x IEEE 1394a, 2 x IEEE 1394b, 2 x LAN (RJ45) port(s), 2 x USB 3.1 Gen 1, 4 x USB 2.0, 1 x Optical S/PDIF out, 6 x Audio jack(s), , Internal I/O Ports, 3 x USB 2.0 connector(s) support(
Warranty Information
8
