Description
90-MIBIN0-G0EAY0MZ - Asus P8Z77-V LE Plus Socket LGA1155 Intel Z77 Chipset ATX System Board Motherboard Supports 3rd/2nd Gen Core i7 / i5 / i3 / Pentium / CeleronSeries DDR3 4x DIMM
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
ATX
CPU Socket Type
LGA 1155
Supported CPU(s)
Intel Celeron Processor, Intel Core i3 Processor, Intel Core i5 Processor, Intel Core i7 Processor, Intel Pentium Processor
Supported CPU Technologies
Intel Turbo Boost Technology
Chipset
Intel Z77 Express
Number of Memory Slot(s)
4
Number of Memory Channel(s)
2
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-12800 (DDR3-1600), PC3-14900 (DDR3-1866), PC3-16000 (DDR3-2000), PC3-19200 (DDR3-2400), PC3-8500 (DDR3-1066)
Maximum Installed Memory
32 GB
Expansion Slots
PCI-E 2.0 x16, PCI-E 3.0 x16
Expansion Slots Details
2 x PCIe 3.0/2.0 x16 (x16 or dual x8, blue) *3, 1 x PCIe 2.0 x16 (x4 mode, black) *4, 2 x PCIe 2.0 x1, 2 x PCI
Storage Controller
SATA 3.0 Gbps, SATA 6.0 Gbps
Audio Controller
Realtek ALC889
Network
Gigabit Ethernet
Connectors/Ports
Audio-In, Audio-Out, Chassis Fan Connector, COM, CPU Fan Connector, HDMI, PS/2 Keyboard, PS/2 Mouse, RJ-45, USB 2.0, USB 3.1
Connectors/Ports Details
Back I/O Ports, 1 x PS/2 keyboard/mouse combo port(s), 1 x DVI, 1 x D-Sub, 1 x DisplayPort, 1 x HDMI, 1 x eSATA, 1 x LAN (RJ45) port(s), 4 x USB 3.1 Gen 1, 2 x USB 2.0, 1 x Optical S/PDIF out, 6 x Audio jack(s), , Internal I/O Ports, 1 x USB 3.1 Gen
Warranty Information
8
