Description
DP45SG - Intel System Board Motherboard Socket T LGA775 1333MHz FSB 1 Pack ATX 1 x Processor Support
Details
Brand
Intel
Weight
8.00 LBS
Form Factor
ATX
CPU Socket Type
LGA775
Supported CPU(s)
Intel Celeron Processor, Intel Core2 Duo Desktop Processor, Intel Core2 Extreme Processor, Intel Core2 Quad Processor, Intel Dual-Core Xeon Processor, Intel Pentium Dual-Core Processor, Intel Quad-Core Xeon Processor
FSB Speed (Maximum)
1333 MHz
Supported CPU Technologies
Dual Core, Enhanced Intel Speedstep Technology, Execute Disable Bit, Idle States, Intel 64 Architecture, Intel Virtualization Technology, Quad Core, Thermal Monitoring Technologies
Chipset
Intel P45 Express
South Bridge Chipset
Intel ICH10R
Number of Memory Slot(s)
4
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-6400 (DDR3-800), PC3-8500 (DDR3-1066)
Maximum Installed Memory
8 GB
Expansion Slots
PCI, PCI Express x1, PCI Express x16
Storage Controller
Serial-ATA 3.0 Gbps
Audio Controller
On-board
Network
Gigabit Ethernet
Connectors/Ports
Audio-In, Audio-Out, FireWire (IEEE 1394), Microphone, RJ-45 (Ethernet), S/PDIF - TOSLINK, USB 2.0
Features
Memory:, Dual Channel Architecture, BIOS:, ACPI support, SMBIOS support, Sleep / Wake Up:, Mouse Wake Up, Wake on USB Port, Keyboard Wake Up, Wake on PCI Device, Suspend to RAM (STR), Hardware:, System Voltage, CPU Core Voltage, CPU Fan Tachometer, C
