Description
DQ35MP - Intel Q35 Express / ICH9DO DDR2 4-Slot Motherboard Socket LGA775
Details
Brand
Intel
Weight
8.00 LBS
Form Factor
Micro ATX
CPU Socket Type
LGA775
Supported CPU(s)
Intel Celeron Processor, Intel Core2 Duo Desktop Processor, Intel Core2 Quad Processor, Intel Pentium Dual-Core Processor
FSB Speed (Maximum)
1333 MHz
Supported CPU Technologies
Enhanced Intel Speedstep Technology, Execute Disable Bit, Hyper-Threading Technology, Idle States, Intel 64 Architecture, Thermal Monitoring Technologies
Chipset
Intel Q35 Express
South Bridge Chipset
Intel ICH9DO
Number of Memory Slot(s)
4
Supported Memory Standard(s)
PC2-5300 (DDR2-667), PC2-6400 (DDR2-800)
Maximum Installed Memory
8 GB
Expansion Slots
PCI, PCI Express x1, PCI Express x16
Storage Controller
(ATA-6) Ultra ATA/100, Serial-ATA 3.0 Gbps
On-Board Video Controller
Intel Graphics Media Accelerator 3100
Audio Controller
Realtek ALC268
Network
Gigabit Ethernet
Connectors/Ports
Audio-In, Audio-Out, Microphone, RJ-45 (Ethernet), USB 2.0, Video-Out
Features
Memory:, Dual Channel Architecture, BIOS:, ACPI support, SMBIOS support, Sleep / Wake Up:, Wake on LAN (WOL), Wake on USB Port, Wake on PCI Device, Suspend to RAM (STR), Hardware Monitoring:, System Voltage, CPU Fan Tachometer, Chassis Temperature, C
