Description
P5QL-VM - Asus Socket LGA775 Intel B43 / ICH10D Chipset Core 2 Quad / Core 2 Extreme / Core 2 Duo / Pentium Processors Support micro-ATX
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
Ultra ATX
CPU Socket Type
LGA 775
Supported CPU(s)
Intel Celeron Processor, Intel Core2 Duo Desktop Processor, Intel Core2 Extreme Processor, Intel Core2 Quad Processor, Intel Pentium Dual-Core Processor
Chipset
Intel B43 Express
South Bridge Chipset
Intel ICH10D
Number of Memory Slot(s)
4
Number of Memory Channel(s)
2
Supported Memory Standard(s)
PC2-5400 (DDR2-667), PC2-6400 (DDR2-800)
Maximum Installed Memory
16 GB
Expansion Slots
PCI, PCI-E 2.0 x16
Storage Controller
SATA 3.0 Gbps
On-Board Video Controller
Intel Graphics Media Accelerator 4500
Audio Controller
VIA VT1705
Network
Gigabit Ethernet
Connectors/Ports
24-pin ATX Power Connector, COM, CPU Fan Connector, D-Sub, DVI, PS/2 Keyboard, PS/2 Mouse, RJ-45, TPM Header, USB 1.1, USB 2.0
Connectors/Ports Details
Back I/O Ports, 1 x DVI, 1 x D-Sub, 1 x PS/2 Keyboard, 1 x PS/2 Mouse , 1 x LAN(RJ45) port , 6 x USB 2.0/1.1 , 1 x COM port , 6 -Channel Audio I/O, 1 x ME Switch, , Internal I/O Ports, 2 x USB connectors support additional 4 USB ports, 6 x SATA conne
