Description
P5QL-VM-EPU - Asus Desktop Board Intel G43 Express Enhanced SpeedStep Technology Socket T 1333MHz, 1066MHz, 800MHz FSB 16GB DDR2 SDRAM DDR2-800/PC2-6400, DDR2-667/PC2-5300 Micro ATX
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
Micro ATX
CPU Socket Type
LGA 775
Supported CPU(s)
Intel Core2 Extreme Processor, Intel Core2 Quad Processor, Intel Pentium Dual-Core Processor
Supported CPU Technologies
Hyper-Threading Technology
Chipset
Intel G43 Express
South Bridge Chipset
Intel ICH10
Number of Memory Slot(s)
4
Number of Memory Channel(s)
2
Supported Memory Standard(s)
PC2-5300 (DDR2-667), PC2-6400 (DDR2-800), PC2-8500 (DDR2-1066)
Maximum Installed Memory
16 GB
Expansion Slots
PCI-E 2.0 x1, PCI-E 2.0 x16
Expansion Slots Details
1 x PCIe 2.0 x16, 1 x PCIe 2.0 x1, 2 x PCI
Storage Controller
SATA 3.0 Gbps
Audio Controller
Realtek ALC887
Network
Gigabit Ethernet
Connectors/Ports
Audio-In, Chassis Fan Connector, CPU Fan Connector, D-Sub, DVI, PS/2 Keyboard, PS/2 Mouse, RJ-45, USB 1.1, USB 2.0
Connectors/Ports Details
Back Panel I/O Ports, 1 x DVI, 1 x D-Sub, 1 x PS/2 Keyboard, 1 x HDMI, 1 x S/PDIF Out (optical), 1 x LAN(RJ45) port, 6 x USB 2.0/1.1, 8 -Channel Audio I/O, , Internal I/O Connectors, 3 x USB connectors (6ports), 1 x IDE connector, 1 x CPU Fan connect
