Description
P8H61-MX-R2.0 - Asus Desktop Motherboard Intel H61 B3 Express Chipset Socket H2 LGA-1155
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
Micro ATX
CPU Socket Type
LGA 1155
Supported CPU(s)
Intel Core i3 Processor, Intel Core i5 Processor, Intel Core i7 Processor
Chipset
Intel H61 Express
Number of Memory Slot(s)
2
Number of Memory Channel(s)
2
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-12800 (DDR3-1600), PC3-14900 (DDR3-1866), PC3-16000 (DDR3-2000), PC3-8500 (DDR3-1066)
Maximum Installed Memory
16 GB
Expansion Slots
PCI-E 2.0 x1, PCI-E 2.0 x16, PCI-E 3.0 x16
Storage Controller
SATA 3.0 Gbps
Audio Controller
VIA VT1708S
Network
Gigabit Ethernet
Connectors/Ports
24-pin ATX Power Connector, Chassis Fan Connector, CPU Fan Connector, D-Sub, DVI, PS/2 Keyboard, PS/2 Mouse, RJ-45, USB 2.0
Connectors/Ports Details
Back I/O Ports, 1 x PS/2 keyboard/mouse combo port(s), 1 x DVI, 1 x D-Sub, 1 x LAN (RJ45) port(s), 6 x USB 2.0, 3 x Audio jack(s), , Internal I/O Ports, 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s), 4 x SATA 3Gb/s connector(s), 1
