Description
P8Q67-M-DO/CSM - Asus Desktop Motherboard Intel Q67 Express Chipset Socket H2 LGA-1155 Micro ATX 1 x Processor Support 16GB DDR3 SDRAM Maximum RAM Serial ATA/600 Yes 1 x PCIe x16 Slot
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
Micro ATX
CPU Socket Type
LGA 1155
Supported CPU(s)
Intel Core i3 Processor, Intel Core i5 Processor, Intel Core i7 Processor
Chipset
Intel Q67 Express
Number of Memory Slot(s)
4
Number of Memory Channel(s)
2
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-8500 (DDR3-1066)
Maximum Installed Memory
32 GB
Expansion Slots
PCI-E 2.0 x16, PCI-E 2.0 x4
Expansion Slots Details
1 x PCIe 2.0 x16, 1 x PCIe 2.0 x4, 2 x PCI
Storage Controller
SATA 3.0 Gbps, SATA 6.0 Gbps
Storage Controller Details
Intel® Q67(B3) chipset, 4 x SATA 3Gb/s port(s), blue, 2 x SATA 6Gb/s port(s), gray, Support Raid 0, 1, 5, 10
Audio Controller
VIA VT1708S
Network
Gigabit Ethernet
Connectors/Ports
Chassis Fan Connector, CPU Fan Connector, DisplayPort, PS/2 Keyboard, PS/2 Mouse, RJ-45, USB 2.0
Connectors/Ports Details
Back I/O Ports, 1 x PS/2 keyboard (purple), 1 x PS/2 mouse (green), 1 x DVI, 1 x D-Sub, 1 x DisplayPort, 1 x LAN (RJ45) port(s), 6 x USB 2.0, 3 x Audio jack(s), , Internal I/O Ports, 4 x USB 2.0 connector(s) support(s) additional 8 USB 2.0 port(s), 1
