Description
P8Z77-I-DELUXE - Asus Desktop Motherboard Intel Z77 Express Chipset Socket H2 LGA-1155
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
Mini-ITX
CPU Socket Type
LGA 1155
Supported CPU(s)
Intel Celeron Processor, Intel Core i3 Processor, Intel Core i5 Processor, Intel Core i7 Processor, Intel Pentium Processor
Supported CPU Technologies
Intel Turbo Boost Technology
Chipset
Intel Z77 Express
Number of Memory Slot(s)
2
Number of Memory Channel(s)
2
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-12800 (DDR3-1600), PC3-14900 (DDR3-1866), PC3-19200 (DDR3-2400)
Maximum Installed Memory
16 GB
Expansion Slots
PCI-E 2.0 x16, PCI-E 3.0 x16
Storage Controller
SATA 3.0 Gbps, SATA 6.0 Gbps
Audio Controller
Realtek ALC898
Network
Gigabit Ethernet
Connectors/Ports
24-pin ATX Power Connector, 8-pin 12V Power Connector, Audio-In, Audio-Out, Chassis Fan Connector, CPU Fan Connector, DisplayPort, DVI-I, TPM Header, USB 2.0, USB 3.1
Connectors/Ports Details
Back I/O Ports, 1 x DVI-I, 1 x DisplayPort, 1 x HDMI, 2 x eSATA 3Gb/s, 1 x LAN (RJ45) port(s), 4 x USB 3.1 Gen 1 , 4 x USB 2.0 , 1 x Optical S/PDIF out, 3 x Audio jack(s), 1 x Clear CMOS button(s), 2 x Wi-Fi antenna port(s), 1 x USB BIOS Flashback Bu
