Description
P9X79-DELUXE - Asus Desktop Motherboard Intel Socket LGA-2011 ATX 1 x Processor Support 64GB DDR3 SDRAM Maximum RAM SLI, CrossFireX Support Serial ATA/600, Serial ATA/300 Yes Controller No 4 x PCIe x16 Slot 6 x USB 3.0 Port Yes
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
ATX
CPU Socket Type
LGA 2011
Supported CPU(s)
Intel Core i7 Processor
Supported CPU Technologies
Intel Turbo Boost Technology
Chipset
Intel X79 Express
Number of Memory Slot(s)
8
Number of Memory Channel(s)
4
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-12800 (DDR3-1600), PC3-14900 (DDR3-1866), PC3-19200 (DDR3-2400), PC3-8500 (DDR3-1066)
Maximum Installed Memory
128GB
Expansion Slots
PCI-E 2.0 x1, PCI-E 2.0 x16, PCI-E 3.0 x16
Expansion Slots Details
3 x PCIe 3.0/2.0 x16 (dual x16 or x16/x8/x8) *1, 1 x PCIe 3.0/2.0 x16 (x8 mode) *1, 2 x PCIe 2.0 x1
Storage Controller
SATA 3.0 Gbps, SATA 6.0 Gbps
Storage Controller Details
Intel X79 chipset, 2 x SATA 6Gb/s port(s), white, 4 x SATA 3Gb/s port(s), blue, Support Raid 0, 1, 5, 10, , Marvell PCIe 9128 controller, 2 x SATA 6Gb/s port(s), white, , ASMedia ASM1061 controller, 2 x Power eSATA 6Gb/s port(s), green
Audio Controller
Realtek ALC898
Network
Gigabit Ethernet
Connectors/Ports
8-pin 12V Power Connector, Audio-In, Audio-Out, Chassis Fan Connector, COM, CPU Fan Connector, RJ-45, USB 2.0, USB 3.1
