Description
P9X79PRO1 - Asus Socket LGA 2011 Intel X79 Chipset 2nd Generation Core i7 Processors Support DDR3 8x DIMM 2x SATA 6.0Gb/s ATX
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
ATX
CPU Socket Type
LGA 2011
Supported CPU(s)
Intel Core i7 Processor
Supported CPU Technologies
Intel Turbo Boost Technology
Chipset
Intel X79 Express
Number of Memory Slot(s)
8
Number of Memory Channel(s)
4
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-12800 (DDR3-1600), PC3-14900 (DDR3-1866), PC3-19200 (DDR3-2400), PC3-8500 (DDR3-1066)
Maximum Installed Memory
128 GB
Expansion Slots
PCI-E 2.0 x1, PCI-E 2.0 x16, PCI-E 3.0 x16
Expansion Slots Details
3 x PCIe 3.0/2.0 x16 (dual x16 or x16/x8/x8) *1, 1 x PCIe 3.0/2.0 x16 (x8 mode) *1, 2 x PCIe 2.0 x1
Storage Controller
SATA 3.0 Gbps, SATA 6.0 Gbps
Audio Controller
Realtek ALC898
Network
Gigabit Ethernet
Connectors/Ports
Audio-In, Audio-Out, Chassis Fan Connector, CPU Fan Connector, PS/2 Keyboard, PS/2 Mouse, RJ-45, USB 2.0, USB 3.1
Connectors/Ports Details
Back I/O Ports, 1 x Bluetooth module(s), 2 x Power eSATA 6Gb/s, 1 x LAN (RJ45) port(s), 4 x USB 3.1 Gen 1, 6 x USB 2.0 (one port can be switched to USB BIOS Flashback®), 1 x Optical S/PDIF out, 6 x Audio jack(s), 1 x USB BIOS Flashback® Button(s), ,
