Description
SABERX99 - Asus SABERTOOTH X99 Socket LGA 2011-v3 Intel X99 Chipset ATX System Board Motherboard Supports Core i7 Series DDR4 8x DIMM
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
ATX
CPU Socket Type
LGA 2011-3
Supported CPU(s)
Intel Core i7 Processor
Supported CPU Technologies
Intel Turbo Boost Technology
Number of Memory Slot(s)
8
Supported Memory Standard(s)
PC4-17000 (DDR4-2133), PC4-19200 (DDR4-2400)
Maximum Installed Memory
64 GB
Expansion Slots
PCI-E 2.0 x16, PCI-E 3.0 x16
Expansion Slots Details
40-Lane CPU, 3 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x16/x8) *1, 28-Lane CPU, 3 x PCIe 3.0/2.0 x16 ( x16, x16/x8, x16/x8/x4) *1, 1 x PCIe 2.0 x4 (x2 mode), 1 x PCIe 2.0 x1
Storage Controller
SATA 6.0 Gbps
Audio Controller
Realtek ALC1150
Network
Gigabit Ethernet
Connectors/Ports
Audio-In, Audio-Out, Chassis Fan Connector, CPU Fan Connector, PS/2 Keyboard, PS/2 Mouse, RJ-45, TPM Header, USB 2.0, USB 3.1
Connectors/Ports Details
Back I/O Ports, 2 x LAN (RJ45) port(s), 2 x LAN (RJ45) port(s), 2 x USB 3.1 Gen 2 (teal blue), 4 x USB 3.1 Gen 1 (blue), 4 x USB 2.0, 1 x Optical S/PDIF out, 5 x Audio jack(s), 1 x USB BIOS Flashback® Button(s), , Internal I/O Ports, 1 x AAFP connect
