Description
SR2FM - Intel Xeon E3-1535M v5 4-Core 2.90GHz 8.00GT/s 8MB L3 Cache Socket FCBGA1440 Processor
Details
Brand
Intel
Weight
2.00 LBS
Processor Type
Mobile
Series
Xeon Processor
Core Model Type/ProcNo.
E3-1535MV5
Processor Code Name
Skylake
Core Stepping
R0
Manufacturing Technology
14 nm
# of Cores
4
# of Threads
8
Clock Speed
2.90 GHz
Max Turbo Frequency
3.80 GHz
L3 Cache Size
8 MB
Front Side Bus / QuickPath Interconnect
8.00 GT/s
Intel Turbo Boost Max Technology 3.0 Frequency
3.80 GHz
Thermal Power
45 Watts
Max Memory Size
64 GB
Memory Types
DDR3L-1600, DDR4-2133, LPDDR3-1866
Memory Channels
2
Maximum Memory Bandwidth
34.1 GB/s
ECC Memory Supported
Yes
CPU Socket Type
FCBGA1449
TJUNCTION
100 °C
Package Size
42mm x 28mm
Processor Graphics
Intel HD Graphics P530
Graphics Base Frequency
350 MHz
Graphics Max Dynamic Frequency
1.05 GHz
Graphics Video Max Memory
1.7 GB
Graphics Output
eDP/DP/HDMI/DVI
4K Support
Yes, at 60Hz
Max Resolution (HDMI 1.4)
4096 x 2304 @ 24Hz
Max Resolution (HDMI)
4096 x 2304 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)
4096 x 2304 @ 60Hz
DirectX Support
12
OpenGL Support
4.4
Intel Quick Sync Video
Yes
Intel InTru 3D Technology
Yes
Intel Clear Video HD Technology
Yes
Intel Clear Video Technology
Yes
# of Displays Supported
3
Device ID
0x191D
Embedded Options Available
No
Scalability
3.0
PCI Express Configurations
1 x16, 1x8+2x4, 2 x8
Max # of PCI Express Lanes
16
Advanced Technologies
Enhanced Intel SpeedStep Technology, Idle States, Instruction Set 64-bit, Intel 64, Intel Flex Memory Access, Intel Hyper-Threading Technology, Intel My WiFi Technology, Intel Smart Response Technology, Intel Stable Image Platform Program (SIPP), Int
Instruction Set Extensions
Intel SSE4.1, Intel SSE4.2, Intel AVX2
Security & Reliability
Execute Disable Bit, Intel AES New Instructions, Intel Memory Protection Extensions (Intel MPX), Intel OS Guard, Intel Software Guard Extensions (Intel SGX), Intel Trusted Execution Technology, Secure Key
Product Condition
OEM
Standard Warranty
21 days
