Description
Z9PE-D8-WS - Asus Workstation Motherboard Intel C602 Chipset Socket R LGA-2011
Details
Brand
ASUS
Weight
8.00 LBS
Form Factor
SSI EEB
CPU Socket Type
LGA 2011
Supported CPU(s)
Intel Xeon Processor
Supported CPU Technologies
64-bit, Hyper-Threading Technology, Intel Turbo Boost Technology, Intel Virtualization Technology
Chipset
Intel C602
Number of Memory Slot(s)
8
Supported Memory Standard(s)
PC3-10600 (DDR3-1333), PC3-12800 (DDR3-1600), PC3-14900 (DDR3-1866), PC3-16000 (DDR3-2000), PC3-8500 (DDR3-1066)
Maximum Installed Memory
256GB
Expansion Slots
PCI-E 2.0 x16, PCI-E 3.0 x16
Expansion Slots Details
4 x PCIe 3.0/2.0 x16 (dual x16 or quad x8) *2, 2 x PCIe 3.0/2.0 x16 *2, 1 x PCIe 3.0/2.0 x16 (x8 mode) *2
Storage Controller
SATA 3.0 Gbps, SATA 6.0 Gbps
Storage Controller Details
2 x SATA 6Gb/s port(s), blue, 8 x SATA 3Gb/s port(s), black, , Marvell PCIe 9230 controller, 4 x SATA 6Gb/s port(s), gray, Support Raid 0, 1, 10
Audio Controller
Realtek ALC898
Network
Gigabit Ethernet
Connectors/Ports
24-pin ATX Power Connector, Audio-In, Audio-Out, CPU Fan Connector, PS/2, PS/2 Keyboard, PS/2 Mouse, S/PDIF, USB 1.1, USB 2.0, USB 3.1
Connectors/Ports Details
Internal I/O Connectors, 1 x USB 3.1 Gen 1 connector(s) support(s) additional 0 USB 3.1 Gen 1 port(s), 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s), 2 x USB 2.0/1.1 vertical port(s), 2 x COM port(s) connector(s), 2 x IEEE 1394a co
